RZ1 Series 8 Pins 24VAC/DC-230VAC 1CO 5A (rezistif) 0,3sec-3min Analog Time Electronic Relay

Product Code
RZ1A1B03M-25
Certificate
CE UKCA
  • Compact design
  • Fast and silent switching
  • Long life
  • Fingerproof design
Switching Capacity
6000/saat
Connection Type
8 Pins
Operating Current
0.04A
Operational Frequency
50 Hz
Operational Voltage
24VAC/DC-230VAC
Product
Electronic Relay
Control
Analog
Type
Time
Contact
1CO
Current (Ie)
5A (rezistif)
Power Consumption
<7VA
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
100000
Operating Temperature
-5°C...+55°C
Protection Degree
IP30
Contact Material
AgNi
Time Interval
0,3sec-3min
Maximum Contact Power
150 W, 1,250 VA
Number of Contact
1 changeover
Repeat Accuracy
±%3
Max. Reset Time
≤100ms
Voltage Interval
(0,85-1.1)*Ue
Indicator
Led
Serial
RZ1 Series
