  5. RZ1 Series 8 Pins 24VAC/DC-230VAC 1CO 5A (rezistif) 0,6sec-6min Analog Time Electronic Relay

Product Details



RZ1 Series 8 Pins 24VAC/DC-230VAC 1CO 5A (rezistif) 0,6sec-6min Analog Time Electronic Relay

Product Code
RZ1A1A06M-25
Certificate
CE UKCA
Downloads
  • Compact design
  • Fast and silent switching
  • Long life
  • Fingerproof design
Serial
RZ1 Series
Indicator
Led
Voltage Interval
(0,85-1.1)*Ue
Max. Reset Time
≤100ms
Repeat Accuracy
±%3
Number of Contact
1 changeover
Maximum Contact Power
150 W, 1,250 VA
Time Interval
0,6sec-6min
Contact Material
AgNi
Protection Degree
IP30
Operating Temperature
-5°C...+55°C
Electrical Life (Min Qty)
100000
Mechanical Life (Min Qty)
10000000
Power Consumption
<7VA
Current (Ie)
5A (rezistif)
Contact
1CO
Type
Time
Control
Analog
Product
Electronic Relay
Operational Voltage
24VAC/DC-230VAC
Operational Frequency
50 Hz
Operating Current
0.04A
Connection Type
8 Pins
Switching Capacity
6000/saat
