Product Details
HN Series 17A 220-230V/50-60HZ Contactor
Product Code
HN1710NUE
Standard
TS EN 60947-4-1
Certificate
Downloads
Operational Frequency
50 - 60Hz
Product
Contactor
Current (Ie)
17A
Usage Category
AC 3
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
1000000
Operating Frequency (On-Off/Hour)
Mech. 1800 Elec. 600
Insulation Voltage (Ui)
690V AC
Impulse Withstand Voltage (Uimp)
6 kV
Dielectric Strength (Body-Contact)
1890V AC
Dielectric Strength (Contact-Contact)
1890V AC
Isolation Resistance
10 MΩ (500 V DC)
Operating Temperature
-15 / +80 °C
Pollution Degree
3
Protection Degree
IP20
Cable Section
2,5 mm²
Screw Torque
1,8 Nm
Short Circuit Breaking Capacity (Ics)
50 kA
Serial
HN Series
Voltage
220-230V/50-60HZ
Auxilliary
1NO
