Product Details
IF Series Multicolor 24V DC 2mt Cable With Buzzer Constant PLC Harmonized M22 Screw LED Beacon 65mm
Product Code
IF6P024ZM05-2
Certificate
Downloads
Operational Frequency
50 Hz
Operational Voltage
24V DC
Product
LED Beacon 65mm
Control
PLC Harmonized
Mounting
M22 Screw
Color
Multicolor
Illumination
Constant
Cable
2mt Cable
Volume
90 - 105 dB
Power Consumption (Red)
1.1W
Power Consumption (Yellow)
1.4W
Power Consumption (Blue)
1.1W
Power Consumption (Green)
1.2W
Power Consumption (White)
2.7W
Power Consumption (Buzzer - Low Level)
0.75W
Power Consumption (Buzzer - High Level)
1.25W
Operating Frequency (On-Off/Hour)
1 Hz
Insulation Voltage (Ui)
300V
Operating Temperature
-25 °C /+70 °C
Protection Degree
IP65
Cable Section
Cable 0,50 mm2
Production Time
31.12.1899 00:00:00
Serial
IF Series
Buzzer
With Buzzer
Electrical Life (Min Hour)
10000
