Product Details
L5 Plastic Body 50 mm Rubber Adjustable Roller Arm With Reset Slow Action 2NO+1NC Limit Switch
Product Code
L5K27MEL122R
Standard
TS EN 60947-5-1
UL 508
VDE 0660
Certificate
![CE](/Images/media/Certificate/thumbs/img_MQ==.jpg?format=webp)
![EAC](/Images/media/Certificate/thumbs/img_Mw==.jpg?format=webp)
![SEPRO](/Images/media/Certificate/thumbs/img_NA==.jpg?format=webp)
![TSE](/Images/media/Certificate/thumbs/img_NQ==.jpg?format=webp)
Certificate
(Contact Block)
(Contact Block)
![TSE](/Images/media/Certificate/thumbs/img_NQ==.jpg?format=webp)
![UL](/Images/media/Certificate/thumbs/img_Ng==.jpg?format=webp)
Downloads
Product
Limit Switch
Feature
With Reset
Contact
2NO+1NC
Actuator
Adjustable Roller Arm
Actuator Dia
50 mm
Current (Ie)
3 A (240V AC)
Usage Category
AC15
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
1000000
Operating Frequency (On-Off/Hour)
Mech. 3000 Elec. 1800
Insulation Voltage (Ui)
300V
Impulse Withstand Voltage (Uimp)
2.5 kV
Dielectric Strength (Body-Contact)
2.500V AC
Dielectric Strength (Contact-Contact)
1.500V AC
Isolation Resistance
10 MΩ (500 V DC)
Operating Temperature
-25 / + 80 °C
Pollution Degree
3
Protection Degree
IP65
Contact Material
AgNi
Cable Section
1-2.5 mm2
Screw Torque
1.5Nm
Short Circuit Breaking Capacity (Ics)
1 kA
Production Time
1.10.2022 00:00:00
Serial
L5 Plastic Body
Contact Action
Slow Action
Actuator Material
Rubber
