  5. L5 Plastic Body 11 mm Plastic Roller Plunger Snap Action 2NC Limit Switch

Product Details



L5 Plastic Body 11 mm Plastic Roller Plunger Snap Action 2NC Limit Switch L5 Plastic Body 11 mm Plastic Roller Plunger Snap Action 2NC Limit Switch

L5 Plastic Body 11 mm Plastic Roller Plunger Snap Action 2NC Limit Switch

Product Code
L5K12MUP331
Standard
TS EN 60947-5-1 UL 508 VDE 0660
Certificate
CE EAC SEPRO TSE UKCA
Certificate
(Contact Block)
TSE UL
Downloads
  • Plastic Body and Cover
  • 1 cable entry suitable for PG13.5 or M20x1.5 optional gland
  • Changeable contact block
  • Different actuator options
L5 Plastic Body 11 mm Plastic Roller Plunger Snap Action 2NC Limit Switch
L5 Plastic Body 11 mm Plastic Roller Plunger Snap Action 2NC Limit Switch
Product
Limit Switch
Serial
L5 Plastic Body
Actuator Dia
11 mm
Actuator Material
Plastic
Actuator
Roller Plunger
Contact Action
Snap Action
Contact
2NC
Current (Ie)
3 A (240V AC)
Usage Category
AC15
Mechanical Life (Min Qty)
10000000
Electrical Life (Min Qty)
1000000
Operating Frequency (On-Off/Hour)
Mech. 3000 Elec. 1800
Insulation Voltage (Ui)
300V
Impulse Withstand Voltage (Uimp)
2.5 kV
Dielectric Strength (Body-Contact)
2.500V AC
Dielectric Strength (Contact-Contact)
1.500V AC
Isolation Resistance
10 MΩ (500 V DC)
Operating Temperature
-25 / + 80 °C
Pollution Degree
3
Protection Degree
IP65
Contact Material
AgNi
Cable Section
1-2.0 mm2
Screw Torque
1.5Nm
1 kA
