Product Details



S Series Plastic 230V AC Red 22 mm Pilot S Series Plastic 230V AC Red 22 mm Pilot

S Series Plastic 230V AC Red 22 mm Pilot

Product Code
S220NK
Certificate
CE UKCA
Downloads
  • Ø10,14, 22 mm round types
  • Different voltage variety
  • Connection facility with different terminal types
S Series Plastic 230V AC Red 22 mm Pilot
S Series Plastic 230V AC Red 22 mm Pilot
Bulb Type
Neon
Operating Current
0.4 mA
Operational Frequency
50 Hz
Operational Voltage
230V AC
Product
Pilot
Color
Red
Dia
22 mm
Power Consumption
0.25 W
Insulation Voltage (Ui)
250 V
Operating Temperature
-15 / + 70 °C
Protection Degree
IP40
Cable Section
1.5-2.5 mm²
Screw Torque
1,5 Nm
Production Time
31.12.1899 00:00:00
Serial
S Series Plastic
Electrical Life (Min Hour)
50000
