Metal Short Lever Roller 1CO MN2 Series Plastic Mini Switch

Product Code
MN2MIM1
Standard
TS EN 60947-5-1
Certificate
CE EAC LIFTINSTITUUT SEPRO TSE
  • Maximum product reliability with V0 material
  • Different actuator options
  • Standard mounting holes
Metal Short Lever Roller 1CO MN2 Series Plastic Mini Switch
Metal Short Lever Roller 1CO MN2 Series Plastic Mini Switch
Product
Plastic Mini Switch
Contact
1CO
Actuator
Short Lever Roller
Current (Ie)
6 A (250V AC)
Usage Category
AC15
Mechanical Life (Min Qty)
500000
Electrical Life (Min Qty)
100000
Operating Frequency (On-Off/Hour)
Mech. 3000 Elec. 1200
Insulation Voltage (Ui)
660V
Impulse Withstand Voltage (Uimp)
2.5 kV
Dielectric Strength (Body-Contact)
1.890V AC
Dielectric Strength (Contact-Contact)
1.890V AC
Isolation Resistance
10 MΩ min. (500V DC)
Operating Temperature
-25 / +80 °C
Pollution Degree
3
Protection Degree
IP20 (IP40 Koruma Kapaklı)
Contact Material
AgNi
Cable Section
1-2.5 mm²
Screw Torque
1,5 Nm
Short Circuit Breaking Capacity (Ics)
1 kA
Serial
MN2 Series
Actuator Material
Metal
